Contrary to initial data after installing a Samsung 970 EVO 1 TB NVMe SSD, I noticed today that the temperatures are quite high in my supersilent case. So I improvised a virtually noiseless fan cooling for it.
Luckily I found a 40mm fan that was silent enough at low speeds. I used two of my ancient and long-unused potentiometer cables connected in series and turned both to minimum. The fan still revs at 2500 RPM it seems, but inaudible from 50 cm distance and farther.
(Sadly I cannot control it in software because the only remaining fan connector on my shitty Asrock board is defective since two days after getting the board and only allows speed control with PWM fans. But I'd still want it in hardware so that it is not annoying outside of Windows where fan control actually works. - Linux is ugh.)
I had to use two wire straps, one with twists at three points, to mostly stabilize the fan in one position. I also put rubber pads on its base to avoid any potential vibration travel onto the PSU case.
Test data:
Process: Copying a 64 GB file at ~300 MB/s. At 70°C and above there was gradual,
gentle throttling down to ~240 MB/s, it seems, unless that was an issue
with the target SSD.
First temperature value is the memory chips, second one the controller.
before cooling ➡️ after cooling
idle = 43°C / 57°C ➡️ 34°C / 48°C (-9 / -9)
load = 51°C / 75°C ➡️ 40°C / 62°C (-11 / -13)
I would have preferred to use a drive benchmark program, but I couldn't find one that simply does continuous max speed reads. (And only reads; I don't want to generate unnecessary writes on it.)
It is a corner with almost no air flow, and this shows what a tremendous difference just a little bit of air flow makes. (Especially in blowing configuration.)
Doesn't matter that it's gonna whirl around there and is not a smooth flow. the turbulence will allow the air pocket there to gradually mix with the main case flow.
I only tested with 300 MB/s. Imagine if you're copying between SSDs at 4-digit speeds, what head load that must be generating. (I'm gonna test that once the new SSD is here, since I need to copy some stuff over then anyway.)
